£10.56
Loading...
Product Range: CoroMill 327Tool Type: Thread millingA versatile cutter which can be used for many types of grooves, threads and chamfers; machining of eccentric components such as gearbox casings, and high volume assemblies, mainly in machining centres and rotating units in lathes.Features & Benefits- Flexible cutter with multiple edges for many types of applications- Low cutting forces- Large program with different shank lengths and diametersApplication- Circlip grooving, Thread milling, Groove milling, Chamfering, both front and back
| Body Material | Steel |
| Damping Property | No |
| Connection Diameter | 50mm |
| Weight | 0.43kg |
| MFR Part No. | 26265094 |
| Standards Met | ISO26623-1 |
| Through Hole Function Property | Yes |
| Functional Diameter | 35mm |
| Data Chip Provision | No |
| Adaptive Interface Workpiece Direction | CoroMill 327 - Size 14 |
| Unit System | Metric |
| Functional Length | 48mm |
| Balanced By Design | No |
| CoroPak | 2.5 |
| Coolant Exit Style Code | 31.75 |
| Coolant Entry Style Code | 0 |
| Rotational Speed Maximum | 28000 1/min |
