TPMR turning inserts feature a tough sub-micron substrate, suitable for low-to-medium cutting speeds. For machining of heat resistant alloys, austenitic stainless steel and hard steel. The 11 positive relief angle is ideal for semi-finishing and finishing of most materials.
Features and Benefits
PVD TiAlN+TiN coating for excellent heat and wear resistance
Tough sub-micron substrate for increased hardness
Semi-finishing/ finishing geometry for finalisation of work pieces
PF chipbreaker for improved chip flow and control
Typical Applications
Turning
Heat resistant alloys
Austenitic stainless steel
Stainless steel
Semi-finishing
Finishing
Standards
Insert Grade IC907
ISO Range - (P10-P30)(M05-M20)(K15-K30)(H05-H15)(S05-S20)(N05-N20)
| Material | Carbide |
| Inscribed Circle | 6.35mm |
| Insert Size | 110304 |
| ISO Category Grade | H | M | P | S |
| ISO Designation | TPMR 110304-PF |
| Thickness | 3.18mm |
| ISO Cut | H05 to H15 | M05 to M20 | P10 to P30 | S05 to S20 |
| Pack Quantity | 1 |
| Clearance Angle | 11\u00b0 |
| Chipbreaker | PF |
| Shape | Triangle |
| Finish/Coating | TiAlN |
| MFR Part No. | 5505569 |
| Cutting Direction | Neutral |
| Manufacturer Grade | IC907 |
| Cutting Edge Length | 11mm |
| Corner Radius | 0.4 |
| Material Application | Hardened Steel | High-Temperature Alloys | Stainless Steels | Steels |
| ISO Category | H | M | P | S |
| Insert Style | TPMR |
