Product Range: CoroMill 390Tool Type: Shoulder millingVersatile shoulder milling cutters with ramping capability for mixed productionFeatures & Benefits- First choice for flexible shoulder milling- 2 cutting edges- Ramping capabilities- Large radius assortment- Internal coolant- Close tolerances giving excellent surface finish and minimal mismatch- Large depth of cut and steep ramping capability- Oversized diameter for clearance is available
| Unit Measured | Metric | Metric |
| Weight | 0.5g |
| Insert Thickness | 2.4mm |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Finish/Coating | AlTiCrN |
| Insert Mounting Style | Screw/Clamp | Screw/Clamp |
| Grade | 1130 |
| Hand Preference | Right |
| Insert Width | 4.06mm |
| Insert Rake Angle | 30\u00b0 |
| Maximum Depth of Cut | 5.8mm |
| Corner Radius | 0.4mm |
| Coating Process Type | PVD |
| Wiper Edge Length | 0.7mm |
| Insert Size/Shape | CoroMill 390 -0702 | CoroMill 390 -0702 |
| Coating Type | AlTiCrN |
| Insert Shape | Rectangle |
| CoroPak | 15.2 |
