Product Range: CoroMill 690The cutting edge for titanium milling.CoroMill 690 is developed specifically for high-productivity 2D profile milling of titanium components. Inserts are securely fastened by iLock technology. By equipping every insert pocket with threaded coolant holes with nozzles for high pressure coolant delivery, you can apply maximum coolant where required.Features & Benefits-- High-productivity milling of titanium and HRSA-material- 4 cutting edge insert- I-Lock interface for security- Internal coolant
| Standards Met | ISO26623-1 |
| Maximum Depth of Cut | 105mm |
| Functional Diameter | 55mm |
| Rotational Speed Maximum | 5000 1/min |
| Body Material | Steel |
| Material | Steel |
| Weight | 4.79kg |
| Connection Diameter | 0.15mm |
| Functional Length | 153mm |
| Usable Length | 120mm |
| CoroPak | 11.5 |
| Center Cutting Capability | 19.05 |
| Through Hole Function Property | Yes |
| Unit Measured | Metric |
| MFR Part No. | 12439136 |
| Maximum Cutting Depth | 105mm |
| Cutting Diameter | 139mm |
| Hand Preference | Right |
| Tool Cutting Edge Angle | 90\u00b0 |
| Maximum Ramping Angle | 0\u00b0 |
