T630 - DIN 371, 374, and 376 - Form C Semi-Bottoming Chamfer - Metric - For Steel and Stainless Steel
| Thread Pitch | 1.5mm |
| Overall Length | 110.0000mm | 110mm |
| Number of Flutes | 4 |
| Thread Diameter | 18mm |
| Adapter Type Machine Side | Cylindrical |
| Cutting Tool Material | Hss-E-Pm |
| Tap Design | S - HSS |
| Unit Measured | Metric |
| MFR Part No. | 3868950 |
| Hand Preference | Right |
| Neck Length | 35.0000mm | 35mm |
| Coating | TiN |
| Thread Length | 15.0000mm |
| Thread Pitch Style | Metric Fine |
| Tap Application | 2 - Blind Hole |
