IC30N Grade description: (P05 - P25). Cermet grade for carbon steel, tool steel, alloy steel, steel casting, malleable cast iron, austenitic stainless steel, martensitic stainless steel, free cutting steel. Suitable for medium speed, medium feed and interrupted cut.
IC9250 (P20-P30 M15-M30) TiCN/Al2O3/TIN multilayer, CVD coated. For grooving/turning forged, low carbon, low alloyed steel parts. For finishing & medium machining of stainless.
IC907 (P10-P30 M05-M20 S05-S20 H05-H15) Tough submicron substrate, TiAIN PVD coated. Suitable for turning heat resistant alloys, austenitic stainless and hard steel at low to medium speeds.
IC9025 (P20-P30 M15-M30) TiCN/Al2O3/TIN multilayer, CVD coated. For roughing/semi-finishing at medium speed. For unstable machining conditions. Very tough.
Chip Breaker: SM. Application: Finish.
Chip Breaker: 14. Application: Finish/Medium.
| Clearance Angle | 7\u00b0 |
| Insert Style | CCMT |
| ISO Cut | M15 to M30 | P20 to P30 |
| Inscribed Circle | 9.525mm |
| ISO Category | M | P |
| Material | Carbide |
| Cutting Edge Length | 9.7mm |
| Cutting Direction | Neutral |
| ISO Category Grade | M | P |
| Manufacturer Grade | IC9250 |
| Insert Size | 09T308 |
| Pack Quantity | 1 |
| Corner Radius | 0.8 |
| ISO Designation | CCMT 09T308-14 |
| Material Application | Stainless Steels | Steels |
| Shape | 80\u00b0 Rhombic |
| Thickness | 3.97mm |
| MFR Part No. | 5504606 |
| Finish/Coating | Al2O3+TiCN+TiN |
