Series A002 - Metric
Standard helix, right hand, wider flutes. 118 point geometry. Suitable for general purpose drilling. TiN coated on working part of the tool. Manufactured to BS328: Part 1: 1986, DIN 338.
| Coolant Delivery | External |
| Shank Diameter Tolerance | F11 |
| Series | A002 |
| Flute Type | Spiral |
| Overall Length | 169mm |
| Point Angle | 118\u00b0 |
| Material | HSS |
| Helix Type | Normal Helix |
| Size | 14.25mm |
| Unit of Measurement | Metric |
| Flute Construction | Ground flutes |
| Product Type | Jobber Drills |
| Cutting Direction | Right Hand |
| MFR Part No. | A00214.25 |
| Drill Diameter Tolerance | H8 |
| Web Thickness | Strengthened |
| Point Type | Split Point |
| Number of Flutes | 2 |
| Drill Diameter | 14.25mm |
| Standards Met | BS 328 | DIN 338 |
| Flute Length | 114mm |
| Finish/Coating | TiN Tipped |
