This range of 60 triangular TCGT turning inserts are suited for use when operating on steels and cast iron. Manufactured from grade 5015 cermet, the inserts are available in a wide range of specifications and are all uncoated. Part of the CoroTurn 107 range, the inserts are designed for superior chip control unobstructed flow of chips when working.
Features and Benefits
Manufactured from grade 5015
Part of the CoroTurn 107 range that emphasises superb chip control and unobstructed flow
Available in a wide range of sizes and specifications to suit your requirements
Uncoated
Typical Applications
Suited for use on steels and cast iron
| Material Application | Steels |
| MFR Part No. | 11061013 |
| Cutting Direction | Left Hand |
| Material | Cermet |
| Pack Quantity | 1 |
| ISO Category | K | P |
| Corner Radius | 0.2 |
| Inscribed Circle | 5.715mm |
| ISO Category Grade | P |
| ISO Designation | TCGT 090202L-K |
| Finish/Coating | Uncoated |
| Chipbreaker | K |
| ISO Cut | P10 |
| Cutting Edge Length | 9.37mm |
| Shape | Triangle |
| Insert Style | TCGT |
| Thickness | 2.38125mm |
| Manufacturer Grade | CT5015 |
| Insert Size | 090202 |
| Clearance Angle | 7\u00b0 |
