Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Basic Standard Group | Coromant |
| Finish/Coating | AlCrN |
| Product Type | CoroMill Plura End Mill |
| Grade | 1630 |
| Shank Type | Cylindrical |
| Maximum Cutting Depth | 30.5mm |
| Standards Met | COROMANT |
| Usable Length | 30.5mm |
| Unit Measured | Metric |
| Rotational Speed Maximum | 45800 1/min |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Functional Length | 83mm |
| Coating Type | AlCrN |
| Center Cutting Capability | Yes |
| Maximum Ramping Angle | 8\u00b0 |
| Maximum Depth of Cut | 30.5mm |
| Coolant Entry Style | Without Coolant |
| Coating Process Type | PVD |
| MFR Part No. | 26259764 |
| Through Hole Function Property | Yes |
| Weight | 0.17kg |
| Connection Diameter | 14mm |
| Material | Solid Carbide |
| CoroPak | 12.2 |
| Cutting Diameter | 14mm |
