Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Rotational Speed Maximum | 80000 1/min |
| Usable Length | 14mm |
| Unit Measured | Metric |
| Through Hole Function Property | Yes |
| Coating Type | TiAlN |
| Standards Met | DIN 6527 K |
| Maximum Ramping Angle | 8\u00b0 |
| Cutting Diameter | 14mm |
| Center Cutting Capability | Yes |
| MFR Part No. | 11589395 |
| Finish/Coating | TiAlN |
| Milling Application | Roughing |
| Grade | 1640 |
| Corner Radius | 0.4mm |
| Maximum Cutting Depth | 14mm |
| Coating Process Type | PVD |
| CoroPak | 3.2 |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Maximum Depth of Cut | 14mm |
| Weight | 165g |
| Material | Solid Carbide |
| Functional Length | 75mm |
| Coolant Entry Style | Without Coolant |
| Connection Diameter | 14mm |
| Basic Standard Group | DIN 6527 K |
