Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Functional Length | 115mm |
| Unit Measured | Metric |
| Finish/Coating | Uncoated |
| Grade | H10F |
| CoroPak | 1.1 |
| Through Hole Function Property | Yes |
| Maximum Depth of Cut | 20mm |
| Cutting Diameter | 16mm |
| Usable Length | 63mm |
| Material | Solid Carbide |
| Maximum Ramping Angle | 15\u00b0 |
| Weight | 0.31kg |
| Coating Type | Uncoated |
| MFR Part No. | 11307144 |
| Rotational Speed Maximum | 80000 1/min |
| Milling Application | Roughing |
| ISO Cutting Tool Material | Uncoated WC |
| Coolant Entry Style | Without Coolant |
| Center Cutting Capability | Yes |
| Basic Standard Group | Coromant |
| Connection Diameter | 40mm |
| Coating Process Type | Uncoated |
| Standards Met | DIN6535 |
| Maximum Cutting Depth | 20mm |
