Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Grade | 1640 |
| Center Cutting Capability | Yes |
| Maximum Cutting Depth | 0.35in |
| Maximum Depth of Cut | 9mm |
| Standards Met | DIN 6527 K |
| Coating Process Type | PVD |
| Coating Type | TiAlN |
| CoroPak | 3.2 |
| Basic Standard Group | DIN 6527 K |
| Rotational Speed Maximum | 80000 1/min |
| Maximum Ramping Angle | 8\u00b0 |
| Milling Application | Roughing |
| Corner Radius | 0.4mm |
| Cutting Diameter | 8mm |
| Connection Diameter | 8mm |
| Finish/Coating | TiAlN |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Unit Measured | Metric |
| Through Hole Function Property | Yes |
| Material | Carbide |
| Usable Length | 9mm |
| MFR Part No. | 11589362 |
| Functional Length | 58mm |
| Coolant Entry Style | Without Coolant | Without Coolant |
