Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Rotational Speed Maximum | 80000 1/min |
| Grade | 1640 |
| Material | Solid Carbide |
| Coolant Entry Style | Without Coolant |
| Coating Type | TiAlN |
| Center Cutting Capability | Yes |
| CoroPak | 3.2 |
| Maximum Ramping Angle | 5\u00b0 |
| Shank Type | Weldon |
| Unit Measured | Metric |
| Connection Diameter | 40mm |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Finish/Coating | TiAlN |
| Functional Length | 83mm |
| Coating Process Type | PVD |
| Through Hole Function Property | Yes |
| Standards Met | DIN 6527 L |
| MFR Part No. | 11589325 |
| Usable Length | 26mm |
| Cutting Diameter | 14mm |
| Basic Standard Group | DIN 6527 L |
| Product Type | Solid Carbide Endmill |
| Maximum Depth of Cut | 26mm |
| Maximum Cutting Depth | 26mm |
| Weight | 0.18kg |
