Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Unit Measured | Metric |
| Rotational Speed Maximum | 80000 1/min |
| Functional Length | 63mm |
| Basic Standard Group | DIN 6527 L |
| Maximum Depth of Cut | 19mm |
| Connection Diameter | 8mm |
| MFR Part No. | 11589292 |
| Maximum Cutting Depth | 0.75in |
| Usable Length | 19mm |
| Grade | 1640 |
| Center Cutting Capability | Yes |
| CoroPak | 3.2 |
| Standards Met | DIN 6527 L |
| Coolant Entry Style | Without Coolant |
| Shank Type | Weldon |
| Finish/Coating | PVD |
| Through Hole Function Property | Yes |
| Maximum Ramping Angle | 5\u00b0 |
| Material | Solid Carbide |
| Cutting Diameter | 8mm |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Coating Process Type | PVD |
| Coating Type | TiAlN |
| Product Type | Solid Carbide Endmill |
