Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Rotational Speed Maximum | 80000 1/min |
| Maximum Ramping Angle | 5\u00b0 |
| Standards Met | DIN 6527 L |
| Coolant Entry Style | Without Coolant |
| Weight | 0.25kg |
| Grade | 1640 |
| Material | Solid Carbide |
| CoroPak | 3.2 |
| MFR Part No. | 11589336 |
| Shank Type | Weldon |
| Basic Standard Group | DIN 6527 L |
| Connection Diameter | 40mm |
| Through Hole Function Property | Yes |
| Coating Type | TiAlN |
| Cutting Diameter | 16mm |
| Unit Measured | Metric |
| Functional Length | 92mm |
| Maximum Cutting Depth | 32mm |
| Product Type | Solid Carbide Endmill |
| Finish/Coating | TiAlN |
| Usable Length | 32mm |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Coating Process Type | PVD |
| Center Cutting Capability | Yes |
| Maximum Depth of Cut | 32mm |
