Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Maximum Depth of Cut | 16mm |
| Center Cutting Capability | Yes |
| Grade | 1620 |
| Rotational Speed Maximum | 80000 1/min |
| Functional Length | 73mm |
| CoroPak | 3.1 |
| Unit Measured | Metric |
| Usable Length | 16mm |
| Cutting Diameter | 12mm |
| Coating Process Type | PVD |
| Basic Standard Group | Coromant |
| Maximum Cutting Depth | 16mm |
| Connection Diameter | 12mm |
| Maximum Ramping Angle | 5\u00b0 |
| Wiper Edge Length | 5mm |
| MFR Part No. | 11561550 |
| Coating Type | TiAlN |
| Coolant Entry Style | Without Coolant |
| Weight | 0.12kg |
| Through Hole Function Property | Yes |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Corner Radius | 1mm |
