Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Functional Length | 100mm |
| Usable Length | 38mm |
| Coating Process Type | PVD |
| Standards Met | COROMANT |
| Coating Type | TiAlN |
| Coolant Entry Style | Without Coolant |
| Maximum Cutting Depth | 38mm |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Product Type | CoroMill Plura End Mill |
| CoroPak | 12.2 |
| Connection Diameter | 32mm |
| Cutting Diameter | 12mm |
| Material | Solid Carbide |
| Unit Measured | Metric |
| Weight | 140.5g |
| Maximum Depth of Cut | 38mm |
| Maximum Ramping Angle | 7\u00b0 |
| Grade | 1620 |
| Basic Standard Group | Coromant |
| Rotational Speed Maximum | 80000 1/min |
| MFR Part No. | 26259816 |
| Center Cutting Capability | Yes |
| Finish/Coating | TiAlN |
| Shank Type | Cylindrical |
| Through Hole Function Property | Yes |
