£4.39
Loading...
Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Basic Standard Group | DIN 6527 L |
| Maximum Cutting Depth | 26mm |
| CoroPak | 12.2 |
| Coating Process Type | PVD |
| Shank Type | Cylindrical |
| Coating Type | TiAlN |
| Maximum Ramping Angle | 5\u00b0 |
| Finish/Coating | TiAlN |
| Connection Diameter | 14mm |
| Product Type | CoroMill Plura End Mill |
| Material | Solid Carbide |
| MFR Part No. | 26259886 |
| Functional Length | 83mm |
| Unit Measured | Metric |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Rotational Speed Maximum | 80000 1/min |
| Usable Length | 26mm |
| Center Cutting Capability | Yes |
| Standards Met | DIN 6527 L |
| Grade | 1620 |
| Through Hole Function Property | Yes |
| Maximum Depth of Cut | 26mm |
| Coolant Entry Style | Without Coolant |
| Cutting Diameter | 14mm |
| Weight | 0.18kg |
