Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Maximum Cutting Depth | 32mm |
| Coating Type | TiAlN |
| Unit Measured | Metric |
| Usable Length | 32mm |
| Through Hole Function Property | Yes |
| Coolant Entry Style | Without Coolant |
| Rotational Speed Maximum | 80000 1/min |
| Basic Standard Group | DIN 6527 L |
| Maximum Depth of Cut | 32mm |
| Weight | 248.5g |
| Standards Met | DIN 6527 L |
| Product Type | CoroMill Plura End Mill |
| Cutting Diameter | 16mm |
| Shank Type | Cylindrical |
| Functional Length | 92mm |
| MFR Part No. | 26259878 |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Center Cutting Capability | Yes |
| Material | Solid Carbide |
| Finish/Coating | TiAlN |
| Grade | 1630 |
| Connection Diameter | 50mm |
| Coating Process Type | PVD |
| Maximum Ramping Angle | 5\u00b0 |
| CoroPak | 12.2 |
