Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| CoroPak | 85 |
| Grade | 1610 |
| Coolant Entry Style | Without Coolant |
| Through Hole Function Property | Yes |
| Corner Radius | 1.5mm |
| Coating Process Type | PVD |
| Cutter Diameter | 3mm |
| Connection Diameter | 1.5mm |
| Unit Measured | Metric |
| Rotational Speed Maximum | 80000 1/min |
| Basic Standard Group | Coromant |
| Usable Length | 4mm |
| Cutting Diameter | 38mm |
| Body Half Taper Angle | 10\u00b0 |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Maximum Ramping Angle | 3\u00b0 |
| MFR Part No. | 11541143 |
| Coating Type | TiAlN |
| Functional Length | 57mm |
