Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| MFR Part No. | 11527666 |
| Body Half Taper Angle | 30\u00b0 |
| Cutter Diameter | 5mm |
| CoroPak | 83 |
| Basic Standard Group | Coromant |
| Connection Diameter | 0.8mm |
| Unit Measured | Metric |
| Coolant Entry Style | Without Coolant |
| Usable Length | 6mm |
| Cutting Diameter | 38mm |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Grade | 1610 |
| Corner Radius | 2.5mm |
| Through Hole Function Property | Yes |
| Coating Process Type | PVD |
| Functional Length | 57mm |
| Coating Type | TiAlN |
| Maximum Ramping Angle | 3\u00b0 |
| Rotational Speed Maximum | 80000 1/min |
