£6.60
Loading...
Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Grade | H10F |
| Maximum Ramping Angle | 15\u00b0 |
| Maximum Cutting Depth | 17mm |
| Center Cutting Capability | Yes |
| Coolant Entry Style | Without Coolant |
| Functional Length | 125mm |
| Connection Diameter | 11.7mm |
| CoroPak | 13.1 |
| Rotational Speed Maximum | 40000 1/min |
| Coating Type | Uncoated |
| Finish/Coating | Uncoated |
| Coating Process Type | Uncoated |
| ISO Cutting Tool Material | Uncoated WC |
| Unit Measured | Metric |
| Through Hole Function Property | Yes |
| Standards Met | COROMANT |
| Cutting Diameter | 12mm |
| Usable Length | 80mm |
| Maximum Depth of Cut | 17mm |
| Weight | 0.19kg |
| Material | Solid Carbide |
| Basic Standard Group | Coromant |
| MFR Part No. | 26261156 |
| Corner Radius | 1.5mm |
