Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| MFR Part No. | 11556451 |
| Weight | 0.44kg |
| Connection Diameter | 63mm |
| Functional Length | 104mm |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Coating Type | TiAlN |
| Material | Solid Carbide |
| Grade | 1620 |
| Coolant Entry Style | Without Coolant |
| Finish/Coating | TiAlN |
| Center Cutting Capability | No |
| Standards Met | DIN 6527 L |
| Product Type | End Mills |
| Through Hole Function Property | Yes |
| Usable Length | 38mm |
| CoroPak | 3.1 |
| Milling Application | Finishing |
| Cutting Diameter | 20mm |
| Maximum Ramping Angle | 3\u00b0 |
| Maximum Depth of Cut | 38mm |
| Maximum Cutting Depth | 38mm |
| Coating Process Type | PVD |
| Basic Standard Group | DIN 6527 L |
| Rotational Speed Maximum | 80000 1/min |
| Unit Measured | Metric |
