Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Through Hole Function Property | Yes |
| Functional Length | 57mm |
| Product Type | End Mills |
| Grade | 1620 |
| Coating Type | TiAlN |
| Maximum Depth of Cut | 13mm |
| Rotational Speed Maximum | 80000 1/min |
| Material | Solid Carbide |
| Connection Diameter | 1mm |
| Weight | 32.4g |
| MFR Part No. | 11556381 |
| Center Cutting Capability | No |
| Finish/Coating | TiAlN |
| Maximum Cutting Depth | 0.51in |
| Milling Application | Finishing |
| Basic Standard Group | DIN 6527 L |
| Unit Measured | Metric |
| CoroPak | 3.1 |
| Usable Length | 13mm |
| Coating Process Type | PVD |
| Maximum Ramping Angle | 3\u00b0 |
| Standards Met | DIN 6527 L |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Coolant Entry Style | Without Coolant | Without Coolant |
| Cutting Diameter | 6mm |
