Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Maximum Depth of Cut | 26mm |
| Corner Radius | 0mm |
| Maximum Cutting Depth | 26mm |
| Usable Length | 26mm |
| Connection Diameter | 14mm |
| Center Cutting Capability | No |
| Rotational Speed Maximum | 80000 1/min |
| Cutting Diameter | 14mm |
| Coating Type | TiAlN |
| Weight | 0.2kg |
| Functional Length | 83mm |
| Finish/Coating | TiAlN |
| Grade | 1610 |
| CoroPak | 7.1 |
| Basic Standard Group | DIN 6527 L |
| Through Hole Function Property | Yes |
| Standards Met | DIN 6527 L |
| Maximum Ramping Angle | 2\u00b0 |
| Product Type | End Mills |
| Material | Solid Carbide |
| Coating Process Type | PVD |
| Milling Application | Finishing |
| ISO Cutting Tool Material | Coated WC or Cermet |
| MFR Part No. | 11528193 |
| Unit Measured | Metric |
| Coolant Entry Style | Without Coolant |
