Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Grade | 1610 |
| Maximum Cutting Depth | 26mm |
| CoroPak | 7.1 |
| Coating Type | TiAlN |
| Through Hole Function Property | Yes |
| MFR Part No. | 11527596 |
| Unit Measured | Metric |
| Coating Process Type | PVD |
| Maximum Depth of Cut | 26mm |
| Maximum Ramping Angle | 2\u00b0 |
| Basic Standard Group | DIN 6527 L |
| Cutting Diameter | 12mm |
| Coolant Entry Style | Without Coolant |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Connection Diameter | 32mm |
| Functional Length | 83mm |
| Center Cutting Capability | No |
| Milling Application | Finishing |
| Weight | 129.3g |
| Finish/Coating | TiAlN |
| Product Type | End Mills |
| Usable Length | 26mm |
| Standards Met | DIN 6527 L |
| Rotational Speed Maximum | 80000 1/min |
| Material | Solid Carbide |
