Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Standards Met | DIN 6527 L |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Maximum Cutting Depth | 22mm |
| Maximum Depth of Cut | 22mm |
| Unit Measured | Metric |
| Product Type | End Mills |
| Grade | 1620 |
| Usable Length | 22mm |
| Basic Standard Group | DIN 6527 L |
| Coating Type | TiAlN |
| Coolant Entry Style | Without Coolant |
| Material | Solid Carbide |
| Functional Length | 72mm |
| CoroPak | 3.1 |
| Center Cutting Capability | No |
| Cutting Diameter | 10mm |
| Finish/Coating | TiAlN |
| Maximum Ramping Angle | 3\u00b0 |
| Milling Application | Finishing |
| Rotational Speed Maximum | 80000 1/min |
| Connection Diameter | 10mm |
| Coating Process Type | PVD |
| Through Hole Function Property | Yes |
| MFR Part No. | 11556403 |
