Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| ISO Cutting Tool Material | Coated WC or Cermet |
| Functional Length | 104mm |
| Maximum Depth of Cut | 38mm |
| Unit Measured | Metric |
| Cutting Diameter | 20mm |
| Center Cutting Capability | No |
| Milling Application | Finishing |
| Coolant Entry Style | Without Coolant |
| Basic Standard Group | DIN 6527 L |
| Corner Radius | 0mm |
| Usable Length | 38mm |
| Coating Process Type | PVD |
| Rotational Speed Maximum | 80000 1/min |
| Coating Type | TiAlN |
| Weight | 477.1g |
| Product Type | End Mills |
| Through Hole Function Property | Yes |
| Maximum Ramping Angle | 2\u00b0 |
| Connection Diameter | 20mm |
| Grade | 1610 |
| CoroPak | 7.1 |
| Maximum Cutting Depth | 38mm |
| Finish/Coating | TiAlN |
| MFR Part No. | 11528215 |
| Material | Solid Carbide |
| Standards Met | DIN 6527 L |
