Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Cutting Diameter | 4mm |
| CoroPak | 7.1 |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Material | Carbide |
| Body Half Taper Angle | 30\u00b0 |
| Milling Application | Finishing |
| Connection Diameter | 6mm |
| Coating Process Type | PVD |
| MFR Part No. | 11527552 |
| Maximum Cutting Depth | 11mm |
| Finish/Coating | TiAlN |
| Product Type | End Mills |
| Body Diameter | 0.16in |
| Usable Length | 11mm |
| Basic Standard Group | DIN 6527 L |
| Standards Met | DIN 6527 L |
| Center Cutting Capability | No |
| Through Hole Function Property | Yes |
| Unit Measured | Metric |
| Rotational Speed Maximum | 80000 1/min |
| Coating Type | TiAlN |
| Coolant Entry Style | Without Coolant |
| Grade | 1610 |
| Functional Length | 57mm |
| Maximum Depth of Cut | 11mm |
| Maximum Ramping Angle | 2\u00b0 |
