Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Center Cutting Capability | Yes |
| Cutting Diameter | 12mm |
| Unit Measured | Metric |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Connection Diameter | 32mm |
| Functional Length | 83mm |
| CoroPak | 12.2 |
| Maximum Ramping Angle | 5\u00b0 |
| Coating Process Type | PVD |
| MFR Part No. | 26259863 |
| Maximum Depth of Cut | 26mm |
| Coating Type | AlCrN |
| Standards Met | DIN 6527 L |
| Material | Solid Carbide |
| Coolant Entry Style | Without Coolant |
| Basic Standard Group | DIN 6527 L |
| Maximum Cutting Depth | 26mm |
| Finish/Coating | AlCrN |
| Grade | 1640 |
| Rotational Speed Maximum | 43800 1/min |
| Weight | 0.12kg |
| Through Hole Function Property | Yes |
| Milling Application | Roughing |
| Usable Length | 26mm |
