Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Usable Length | 15.875mm |
| Coating Type | TiAlN |
| Maximum Cutting Depth | 15.88mm |
| Material | Solid Carbide |
| Coolant Entry Style | Without Coolant |
| Coating Process Type | PVD |
| Unit Measured | Imperial |
| Through Hole Function Property | Yes |
| Rotational Speed Maximum | 80000 1/min |
| Standards Met | COROMANT |
| Center Cutting Capability | Yes |
| MFR Part No. | 5739441 |
| Shank Type | Cylindrical |
| Maximum Depth of Cut | 15.88mm |
| Maximum Ramping Angle | 5\u00b0 |
| Cutting Diameter | 7.94mm |
| Functional Length | 88.9mm |
| Connection Diameter | 25.4mm |
| Grade | 1630 |
| CoroPak | 3.1 |
| Corner Radius | 0.397mm |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Basic Standard Group | Coromant |
| Product Type | Solid Carbide Endmill |
