Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Product Type | Solid Carbide Endmill |
| Maximum Depth of Cut | 22mm |
| Basic Standard Group | Coromant |
| Coating Type | TiAlN |
| Maximum Ramping Angle | 5\u00b0 |
| Standards Met | COROMANT |
| Shank Type | Cylindrical |
| Weight | 0.12kg |
| Grade | 1620 |
| Functional Length | 100mm |
| Unit Measured | Metric |
| Cutting Diameter | 10mm |
| Center Cutting Capability | Yes |
| Maximum Cutting Depth | 22mm |
| Coating Process Type | PVD |
| Rotational Speed Maximum | 80000 1/min |
| CoroPak | 9.2 |
| Coolant Entry Style | Without Coolant |
| Corner Radius | 2mm |
| Material | Solid Carbide |
| Usable Length | 42mm |
| MFR Part No. | 5742935 |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Connection Diameter | 25mm |
| Through Hole Function Property | Yes |
