Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Corner Radius | 0.794mm |
| Coolant Entry Style | Without Coolant |
| Usable Length | 25.4mm |
| Maximum Depth of Cut | 25.4mm |
| Cutting Diameter | 7.938mm |
| Maximum Ramping Angle | 3\u00b0 |
| Unit Measured | Imperial |
| Material | Solid Carbide |
| Rotational Speed Maximum | 80000 1/min |
| Product Type | End Mills |
| Grade | 1620 |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Functional Length | 88.9mm |
| Milling Application | Finishing |
| CoroPak | 3.1 |
| Through Hole Function Property | Yes |
| Center Cutting Capability | No |
| Connection Diameter | 25.4mm |
| MFR Part No. | 5739939 |
| Basic Standard Group | Coromant |
| Coating Type | TiAlN |
| Maximum Cutting Depth | 25.4mm |
| Coating Process Type | PVD |
