Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Weight | 0.47kg |
| MFR Part No. | 5739938 |
| Basic Standard Group | Coromant |
| Corner Radius | 1.588mm |
| Coolant Entry Style | Without Coolant |
| Material | Solid Carbide |
| CoroPak | 3.1 |
| Connection Diameter | 19.05mm |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Unit Measured | Imperial |
| Center Cutting Capability | Yes |
| Maximum Ramping Angle | 5\u00b0 |
| Maximum Depth of Cut | 57.15mm |
| Rotational Speed Maximum | 80000 1/min |
| Shank Type | Cylindrical |
| Cutting Diameter | 19.05mm |
| Grade | 1620 |
| Functional Length | 127mm |
| Through Hole Function Property | Yes |
| Standards Met | COROMANT |
| Maximum Cutting Depth | 57.15mm |
| Coating Type | TiAlN |
| Coating Process Type | PVD |
| Usable Length | 57.15mm |
| Product Type | Solid Carbide Endmill |
