Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Standards Met | COROMANT |
| Corner Radius | 0.794mm |
| Maximum Depth of Cut | 38.1mm |
| CoroPak | 3.1 |
| Shank Type | Cylindrical |
| Center Cutting Capability | Yes |
| Weight | 0.18kg |
| Unit Measured | Imperial |
| Usable Length | 38.1mm |
| Rotational Speed Maximum | 80000 1/min |
| Basic Standard Group | Coromant |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Coolant Entry Style | Without Coolant |
| MFR Part No. | 5739982 |
| Maximum Cutting Depth | 38.1mm |
| Material | Solid Carbide |
| Functional Length | 101.6mm |
| Connection Diameter | 11mm |
| Coating Process Type | PVD |
| Coating Type | TiAlN |
| Cutting Diameter | 12.7mm |
| Product Type | Solid Carbide Endmill |
| Through Hole Function Property | Yes |
| Grade | 1620 |
| Maximum Ramping Angle | 5\u00b0 |
