Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Unit Measured | Imperial |
| Cutting Diameter | 12.7mm |
| Corner Radius | 1.588mm |
| Rotational Speed Maximum | 80000 1/min |
| Weight | 183g |
| Standards Met | COROMANT |
| Shank Type | Cylindrical |
| Coating Process Type | PVD |
| Material | Solid Carbide |
| Usable Length | 38.1mm |
| Connection Diameter | 11mm |
| Through Hole Function Property | Yes |
| CoroPak | 3.1 |
| Basic Standard Group | Coromant |
| Coolant Entry Style | Without Coolant |
| Maximum Ramping Angle | 5\u00b0 |
| Maximum Cutting Depth | 38.1mm |
| Functional Length | 101.6mm |
| MFR Part No. | 5739988 |
| Maximum Depth of Cut | 38.1mm |
| Product Type | Solid Carbide Endmill |
| Coating Type | TiAlN |
| Center Cutting Capability | Yes |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Grade | 1620 |
