Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Functional Length | 114.3mm |
| Unit Measured | Imperial |
| Shank Type | Cylindrical |
| Weight | 0.32kg |
| Standards Met | COROMANT |
| Product Type | Solid Carbide Endmill |
| MFR Part No. | 5739990 |
| Connection Diameter | 15.875mm |
| Basic Standard Group | Coromant |
| Coating Type | TiAlN |
| Cutting Diameter | 15.875mm |
| Coolant Entry Style | Without Coolant |
| CoroPak | 3.1 |
| Center Cutting Capability | Yes |
| Usable Length | 31.75mm |
| Material | Solid Carbide |
| Rotational Speed Maximum | 80000 1/min |
| Maximum Cutting Depth | 31.75mm |
| Through Hole Function Property | Yes |
| Corner Radius | 0.794mm |
| Grade | 1630 |
| Maximum Depth of Cut | 31.75mm |
| Maximum Ramping Angle | 5\u00b0 |
| Coating Process Type | PVD |
| ISO Cutting Tool Material | Coated WC or Cermet |
