Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| ISO Cutting Tool Material | Coated WC or Cermet |
| MFR Part No. | 7045741 |
| Through Hole Function Property | Yes |
| Material | Solid Carbide |
| Coating Type | AlCrN |
| Cutting Diameter | 4.763mm |
| Shank Type | Cylindrical |
| Grade | 1630 |
| CoroPak | 16.2 |
| Rotational Speed Maximum | 80000 1/min |
| Usable Length | 9.525mm |
| Maximum Depth of Cut | 9.53mm |
| Maximum Cutting Depth | 9.53mm |
| Unit Measured | Imperial |
| Coating Process Type | PVD |
| Coolant Entry Style | Without Coolant |
| Functional Length | 50.8mm |
| Maximum Ramping Angle | 5\u00b0 |
| Center Cutting Capability | Yes |
| Connection Diameter | 4.7625mm |
