Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Through Hole Function Property | Yes |
| Grade | 1630 |
| Coating Process Type | PVD |
| Weight | 0.39kg |
| Center Cutting Capability | Yes |
| Usable Length | 31.75mm |
| CoroPak | 16.2 |
| Maximum Depth of Cut | 31.75mm |
| Material | Solid Carbide |
| Shank Type | Cylindrical |
| Rotational Speed Maximum | 15300 1/min |
| Connection Diameter | 19.05mm |
| Coating Type | AlCrN |
| MFR Part No. | 7045746 |
| Functional Length | 101.6mm |
| Coolant Entry Style | Without Coolant |
| Maximum Ramping Angle | 5\u00b0 |
| Cutting Diameter | 19.05mm |
| Unit Measured | Imperial |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Maximum Cutting Depth | 31.75mm |
