Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| CoroPak | 16.2 |
| Rotational Speed Maximum | 70000 1/min |
| Basic Standard Group | INTERNAL |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Material | Solid Carbide |
| Center Cutting Capability | Yes |
| Through Hole Function Property | Yes |
| Maximum Ramping Angle | 5\u00b0 |
| Coolant Entry Style | Without Coolant |
| Connection Diameter | 38.1mm |
| Milling Application | Roughing |
| Grade | 1640 |
| Coating Process Type | PVD |
| Unit Measured | Imperial |
| Maximum Cutting Depth | 21.43mm |
| Maximum Depth of Cut | 21.43mm |
| Coating Type | AlCrN |
| MFR Part No. | 7045757 |
| Cutting Diameter | 9.525mm |
| Usable Length | 21.43mm |
| Functional Length | 76.2mm |
