Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Basic Standard Group | INTERNAL |
| Coating Process Type | PVD |
| MFR Part No. | 7045783 |
| Rotational Speed Maximum | 80000 1/min |
| Maximum Depth of Cut | 18.26mm |
| Center Cutting Capability | Yes |
| Grade | 1620 |
| Shank Type | Cylindrical |
| Maximum Cutting Depth | 18.26mm |
| Coating Type | TiAlN |
| Cutting Diameter | 9.525mm |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Usable Length | 18.26mm |
| Unit Measured | Imperial |
| Through Hole Function Property | Yes |
| Coolant Entry Style | Without Coolant |
| Functional Length | 63.5mm |
| Maximum Ramping Angle | 8\u00b0 |
| Connection Diameter | 38.1mm |
| CoroPak | 16.2 |
| Material | Solid Carbide |
