Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Connection Diameter | 4.7625mm |
| Basic Standard Group | INTERNAL |
| Functional Length | 50.8mm |
| Usable Length | 9.525mm |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Maximum Cutting Depth | 9.53mm |
| Unit Measured | Imperial |
| MFR Part No. | 7045781 |
| Center Cutting Capability | Yes |
| Grade | 1620 |
| Coating Type | TiAlN |
| CoroPak | 16.2 |
| Coolant Entry Style | Without Coolant |
| Through Hole Function Property | Yes |
| Cutting Diameter | 4.763mm |
| Maximum Depth of Cut | 9.53mm |
| Shank Type | Cylindrical |
| Maximum Ramping Angle | 8\u00b0 |
| Coating Process Type | PVD |
| Rotational Speed Maximum | 80000 1/min |
| Material | Solid Carbide |
