Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Unit Measured | Metric |
| CoroPak | 12.2 |
| Through Hole Function Property | Yes |
| Coolant Entry Style | Without Coolant |
| Connection Diameter | 14.65mm |
| Rotational Speed Maximum | 80000 1/min |
| MFR Part No. | 6259477 |
| Maximum Cutting Diameter | 6mm |
| Functional Length | 56.5mm |
| Coating Process Type | PVD |
| Coating Type | TiAlN |
| Maximum Depth of Cut | 2.5mm |
| Basic Standard Group | Coromant |
| Material | Solid Carbide |
| Grade | 1620 |
| Standards Met | COROMANT |
| Tool Cutting Edge Angle | 45\u00b0 |
| Cutting Diameter | 1mm |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Maximum Cutting Depth | 2.5mm |
