Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Maximum Depth of Cut | 7.54mm |
| Shank Type | Cylindrical |
| Rotational Speed Maximum | 80000 1/min |
| Coating Process Type | PVD |
| Cutting Diameter | 3.175mm |
| Corner Radius | 0mm |
| MFR Part No. | 7045780 |
| Usable Length | 7.54mm |
| Coolant Entry Style | Without Coolant |
| Center Cutting Capability | Yes |
| Maximum Ramping Angle | 8\u00b0 |
| Coating Type | TiAlN |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Maximum Cutting Depth | 7.54mm |
| Material | Solid Carbide |
| Functional Length | 38.1mm |
| Connection Diameter | 3.175mm |
| Grade | 1620 |
| CoroPak | 16.2 |
| Through Hole Function Property | Yes |
| Unit Measured | Imperial |
