Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Standards Met | COROMANT |
| Grade | 1740 |
| Center Cutting Capability | Yes |
| Through Hole Function Property | Yes |
| MFR Part No. | 6732507 |
| Cutting Diameter | 6.35mm |
| CoroPak | 15.1 |
| Material | Solid Carbide |
| Corner Radius | 0.762mm |
| Maximum Ramping Angle | 5\u00b0 |
| Maximum Cutting Depth | 15.88mm |
| Maximum Depth of Cut | 15.88mm |
| Coating Process Type | PVD |
| Coating Type | AlTiN |
| Usable Length | 15.875mm |
| Rotational Speed Maximum | 80000 1/min |
| Connection Diameter | 6.35mm |
| Functional Length | 63.5mm |
| Basic Standard Group | Coromant |
| Coolant Entry Style | 1 |
| Unit Measured | Imperial |
| ISO Cutting Tool Material | Coated WC or Cermet |
