Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Product Type | Solid Carbide Endmill |
| Functional Length | 121mm |
| Center Cutting Capability | No |
| Shank Type | Cylindrical |
| Material | Solid Carbide |
| Standards Met | DIN6535 |
| Basic Standard Group | Coromant |
| Through Hole Function Property | Yes |
| Grade | 1745 |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Coating Process Type | PVD |
| Connection Diameter | 25mm |
| Unit Measured | Metric |
| Maximum Ramping Angle | 5\u00b0 |
| Coating Type | TiAlSiN |
| MFR Part No. | 7419226 |
| Usable Length | 63mm |
| Corner Radius | 4mm |
| Rotational Speed Maximum | 8200 1/min |
| Weight | 780g |
| Maximum Depth of Cut | 52mm |
| Coolant Entry Style | 1 |
| Cutting Diameter | 25mm |
| Maximum Cutting Depth | 52mm |
| CoroPak | 17.2 |
