Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| MFR Part No. | 7419231 |
| Rotational Speed Maximum | 8200 1/min |
| Usable Length | 63mm |
| Grade | 1745 |
| Maximum Ramping Angle | 5\u00b0 |
| Basic Standard Group | Coromant |
| Weight | 708g |
| Standards Met | COROMANT |
| Coating Process Type | PVD |
| ISO Cutting Tool Material | Coated WC or Cermet |
| CoroPak | 17.2 |
| Maximum Depth of Cut | 52mm |
| Product Type | Solid Carbide Endmill |
| Unit Measured | Metric |
| Cutting Diameter | 25mm |
| Material | Carbide |
| Corner Radius | 4mm |
| Coating Type | TiAlSiN |
| Through Hole Function Property | Yes |
| Shank Type | Weldon |
| Connection Diameter | 6mm |
| Maximum Cutting Depth | 52mm |
| Functional Length | 121mm |
| Center Cutting Capability | No |
| Coolant Entry Style | 1 |
