Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Grade | 1730 |
| Maximum Depth of Cut | 22.23mm |
| Coating Process Type | PVD |
| Coating Type | AlCrN |
| Maximum Cutting Depth | 22.23mm |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Cutting Diameter | 9.525mm |
| Connection Diameter | 9.525mm |
| Basic Standard Group | Coromant |
| Functional Length | 63.5mm |
| Unit Measured | Imperial |
| MFR Part No. | 6732540 |
| Coolant Entry Style | Without Coolant |
| Rotational Speed Maximum | 80000 1/min |
| Center Cutting Capability | Yes |
| CoroPak | 15.1 |
| Through Hole Function Property | Yes |
| Maximum Ramping Angle | 7\u00b0 |
| Standards Met | COROMANT |
| Usable Length | 22.225mm |
| Material | Solid Carbide |
