Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Material | Solid Carbide |
| Usable Length | 36mm |
| Product Type | Solid Carbide Endmill |
| CoroPak | 20.2 |
| Maximum Depth of Cut | 26mm |
| Coating Type | TiAlN |
| Coolant Entry Style | Without Coolant |
| Weight | 0.12kg |
| Rotational Speed Maximum | 40000 1/min |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Basic Standard Group | DIN 6527 L |
| Functional Length | 83mm |
| Shank Type | Weldon |
| Maximum Ramping Angle | 5\u00b0 |
| Maximum Cutting Depth | 26mm |
| Grade | 1725 |
| Center Cutting Capability | Yes |
| Cutting Diameter | 12mm |
| Through Hole Function Property | Yes |
| Unit Measured | Metric |
| MFR Part No. | 7858268 |
| Standards Met | DIN 6527 L |
| Coating Process Type | PVD |
| Connection Diameter | 40mm |
