Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Maximum Ramping Angle | 7\u00b0 |
| Usable Length | 22mm |
| Cutting Diameter | 10mm |
| Connection Diameter | 10mm |
| Coating Type | AlCrN |
| Basic Standard Group | Coromant |
| Coating Process Type | PVD |
| MFR Part No. | 7716331 |
| Rotational Speed Maximum | 72600 1/min |
| Coolant Entry Style | Without Coolant |
| Maximum Depth of Cut | 22mm |
| Unit Measured | Metric |
| Center Cutting Capability | Yes |
| CoroPak | 20.1 |
| Through Hole Function Property | Yes |
| Grade | 1730 |
| Maximum Cutting Depth | 22mm |
| Functional Length | 72mm |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Standards Met | COROMANT |
| Material | Solid Carbide |
